DIATONE MAMBA KN2808 1100KV Brushless Motor 4-6S

DIATONE MAMBA KN2808 1100KV Brushless Motor W/ 6mm titanium alloy shaft Compatible 7inch Propeller 4-6S for FPV Racing Drone

Description

• MAMBA KN 2808 1100KV

• Color: black

• Overall Dimension:Φ35.1×40.3mm

• prop mounting shaft diameter:5mm

• Installation hole position:19×19mm,M3

• Prop: 7 inch

• Bottom Bearing:13*6*5

• Top Bearing:10*6*4

• slots/poles:12N14P

• Shaft Diameter:6.0mm

• Magnet Wire: 240℃ Enameled Wire

• Stator Diamter:28mm

• Stator Height:8mm

• Rated Voltage:4~6S (16.8V~25.2V)

• Peak Current:38.7A

• ladle Current:1.2A

• Maximum Power: 862.5W

• Internal Resistance:68mΩ

• Weight 63.5g
